Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing

Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing

Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing

Place of Origin	Jiangsu,China
Brand Name	CHINALCO
Certification	ISO9001
Model Number	1000series, 2000series, 3000series, 5000series, 6000series, 7000series
Document	Product Brochure PDF

Product Details

Product Name:

Aluminum Pipe

Material:

1050,1060,1070,1100,2A11, 2A12,2014,2024, 5052, 5A02, 5A06,5083,6060,6061,6063, 6082,6351, 6A02,7075,7005,7A04

Thickness:

0.6-20mm Or As Required

Diameter:

2-100mm Or As Required

Surface:

Mill Finish,Anodize Or As Required

Delivery Time:

About 7-10 Days,depends On The Specific Order

Trade Terms:

FOB CIF CFR EXW

Packing:

Standard Seaworthy Packing

Highlight:

Small Diameter 3003 Aluminium Pipe

,

Mill Finish Customized Packing Aluminium Pipe

,

ASTM B211 5083 Aluminium Pipe

Payment & Shipping Terms

Minimum Order Quantity

1ton

Price

Negotiable

Packaging Details

Exporting package/wooden box package/Or per customers’requirement

Delivery Time

3-15 days

Payment Terms

L/C, T/T, Western Union

Supply Ability

2000 Ton/Tons per Month

Product Description

Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing

Product Description

Aluminum tube is a kind of nonferrous metal tube, which refers to the metal tubular material extruded from pure aluminum
or aluminum alloy to be hollow along its longitudinal full length.

According to the shape, it can be divided into square pipe, round pipe, riffled pipe, profiled pipe and universal aluminum pipe.
It can be divided into seamless aluminum tube and ordinary extruded tube according to extrusion mode.

The alloy aluminum tube profile is mainly produced by the extrusion method, the most commonly used extrusion processes
are forward extrusion and reverse extrusion. Extruded alloy aluminum pipes and profiles adopt the production process of
ingot heating-extrusion-finishing; for heat-treated aluminum alloys that can be strengthened, quenching and aging treatment
re also required.

Aluminum Pipe/Tube
Aluminum Pipe/Tube
1000 Series	Industrial Pure Aluminum(1050,1060 ,1070, 1100)
2000 Series	Aluminum-copper alloys(2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17)
3000 Series	Aluminum-manganese alloys(3A21, 3003, 3103, 3004, 3005, 3105)
4000 Series	Al-Si alloys(4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A)
5000 Series	Al-Mg alloys(5052, 5083, 5754, 5005, 5086,5182)
6000 Series	Aluminum Magnesium Silicon Alloys(6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02)
7000 Series	Aluminum, Zinc, Magnesium and Copper Alloys(7075, 7A04, 7A09, 7A52, 7A05)
Wall Thickness	0.6mm-20mm, or as required
Outer Diameter	2mm-100mm, or as required
Length	1000mm-6000mm, or as required
Application	Lid Stock. Industrial Device, Storage. All Kinds of Containers, etc.
MOQ	500kg
Feature	Lid Shigh conductivity, good corrosion resistant performance, high latent heatof melting, high-reflectance, well weldingproperty*, low strength, and notsuitable for heat treatments.

Product Detail

Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing 0

Chemical Compositon

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Zr
Impurity	Al	2014	0.5-1.2	0.7	3.9-5.0	0.4-1.2	0.2-0.8	0.1	0.25
0.15	-	0.15	Rest	2017	0.2-0.8	0.7	3.5-4.5	0.4-1.0	0.4-0.8
0.1	0.25	0.15	-	0.15	Rest	2024	0.5	0.5	3.8-4.9
0.3-0.9	1.2-1.8	0.1	0.25	0.15	-	0.15	Rest	5052	0.25
0.4	0.1	0.1	2.2-2.8	0.15-0.35	0.1	-	-	0.15	Rest
5056	0.3	0.4	0.1	0.05-0.20	4.5-5.6	0.05-0.20	0.1	-	-
0.15	Rest	5083	0.4	0.4	0.1	0.40-1.0	4.0-4.9	0.05-0.25	0.25
0.15	-	0.15	Rest	5754	0.4	0.4	0.1	0.5	2.6-3.6
0.3	0.2	0.15	-	0.15	Rest	6061	0.4-0.8	0.70	0.15-0.40
0.15	0.8-1.2	0.04-0.35	0.25	0.15	-	0.15	Rest	6063	0.2-0.6
0.35	0.1	0.1	0.45-0.9	0.1	0.1	0.1	-	0.15	Rest
6082	0.7-1.3	0.5	0.1	0.4-1.0	0.6-1.2	0.25	0.2	0.1	-

Physical Properties

Physical Properties		Tensile Strength	Yield Strength	Elongation(%)
Grade	Hardness	(MPa)	(MPa)	0.25-1.25mm	1.26-3.0mm
Grade	Hardness	(MPa)	(MPa)	0.25-1.25mm	1.26-3.0mm
1100	O	89.6	34.5	30	6
	H12	110.3	103.4	4	12
	H14	124.1	117.2	3	10
2024	O	186.2	75.8	18	20
	T3	482.6	344.7	16	18
	T4	468.8	324.1	20	19
3003	O	110.3	41.4	30	33
	H12	131	124.1	9	11
	H14	151.7	144.8	3	7
5052	O	193.1	89.6	20	21
	H32	227.5	193.1	7	10
	H34	262	213.7	6	8
5083	O	275.8	144.8	21	25
	H32	282.7	151.7	20	21
	H34	330.9	255.1	11	14
6061	O	124.1	55.2	25	26
	T4	241.3	144.8	22	24
	T6	310.3	275.8	12	17
7075	O	227.5	103.4	16	18
7075	T6	572.3	503.3	11	12

Test

Provided Service

Recommend Products

Application

Small Diameter 3003 Aluminium Pipe 5083 Mill Finish ASTM B211 Customized Packing 4

Packing & Shipping

Certificate

FAQ

Q:Can I get some samples?
A: Yes, sample order is available for quality check and market test. But you have to pay the sample cost and express cost.

Q: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.

Q: What's the lead time?
A: According to the order quantity, small order usually need 3-5 days, big order need negotiation.
