GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications
  • GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications
  • GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications
  • GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications
GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications

Place of Origin Jiangsu,China
Brand Name CHINALCO
Certification ISO9001
Model Number 1000series, 2000series, 3000series, 5000series, 6000series, 7000series
Document Product Brochure PDF
Product Details
Key Word:
Aluminum Tube
Diameter:
2 - 200mm Or As Required
Tolerance:
±1%
Wall Thickness:
0.2mm - 150mm Or As Required
Shape:
Round,square,rectangle
Hardness:
Hard
Manufacturing Technology:
Drawn,extruded,forged,etc
Application:
Refrigerator, Air Condition, Automobile, Water Heater
Highlight:

6000 Series Aluminium Pipe

,

7000 Series Aluminium Pipe

,

Marine Applications Aluminium Pipe

Payment & Shipping Terms
Minimum Order Quantity
1ton
Price
Negotiable
Packaging Details
Exporting package/wooden box package/Or per customers’requirement
Delivery Time
3-15 days
Payment Terms
L/C, T/T, Western Union
Supply Ability
2000 Ton/Tons per Month
Product Description

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications​

Product Description



Alminuum tube is a kind of non-ferrous metal tube, which refers to a metal tubular material that is hollow along its longitudinal length by extruding pure aluminum or aluminum alloy. Aluminum alloy pipe is a kind of metal material with light weight, low conductivity, high corrosion resistance, good strength and other excellent properties, widely used in metallurgy, cold working, pipe fittings manufacturing and other lines. The main use of pipe fittings is not in connection, but also an important engineering surface treatment material. Aluminum tubes are widely used in all walks of life, such as: automobiles, ships, aerospace, aviation, electrical appliances, agriculture, electrical, home and so on.



Item
Aluminum Tube
Material
6000 series Aluminium
Temper
T4, T5, T6
Size / Thickness
General profiles thickness from 0.8 to 5.0mm, length from 3m-6m or customized available; Anodize protection film thickness from
8~25 um, powder coating from 40 ~ 120 um.
Shape
Square, round, rectangular, customized
Application
In furniture, windows&doors, decorations ,industry, construction and so on
Surface Treatment
Powder coating, electrophoresis, wood grain , anodized and so on
Colors
Ref powder coating color sheet and customized color available
Deep Process
CNC, drilling, milling, cutting, welding, bending, assembling
Packing Details
(1)Inside : packed with plastic protective film to protect each piece
(2) Outside: Wrap to be bundles by waterproof craft paper
Delivery Time
(1)Die Developing and Sample testing: 12-18 days .
(2) Mass Production completed: 20-30days after sample is confirmed by Buyer.
FOB Port
TIANJIN/QINGDAO
payment Terms
T/T 30% for deposit, balance before shipping.
settlement Term
Charge by final actual weight or by drawing theoretical weight.
Production capacity
5000 tons monthly, 60000 tons annually.
Certificate and Standard
CQM, SGS, CE, BV, SONCAP / GB, ISO, JIS, AS, NZS, QUALICOAT, QUOLANOD available
Guarantee
Surface color can be stable for many indoor using.


Product Detail

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 0

Chemical Compositon



Grade IS ON OR 209 Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1050 Al99.5 0.25 0.4 0.05 0.05 0.05 - - 0.05 - 99.5
1060 Al99.6 0.25 0.35 0.05 0.03 0.03 - - 0.04 - 99.7
1070 Al99.7 0.2 0.25 0.04 0.03 0.03 - - 0.04 - 99.7
1100 Al99.0Cu Si+Fe:0.95 0.05-0.2 0.05 - - 0.1 - - 99
2014 Cu4SiMg 0.50-1.2 0.7 3.9-0.5 0.40-1.2 0.20-0.8 0.1 - 0.25 0.15 99
2017 Cu4MgSi 0.20-0.8 0.7 3.5-4.5 0.40-1.0 0.40-1.0 - - 0.3 - 99
2024 Cu4Mg1 0.5 0.5 3.8-4.9 0.30-0.9 1.2-1.8 0.1 - 0.25 0.15 99
3003 Al Mn1Cu 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - 99
5005 AlMg1(B) 0.3 0.7 0.2 0.2 0.50-1.1 0.1 - 0.25 - 99
5042 Al Mg3.5Mn 0.2 0.35 0.15 0.20-0.50 3.0-4.0 0.1 - 0.25 0.1 99
5052 Al Mg2.5 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 - 0.1 - 99
5083 Al Mg4.5Mn0.7 0.4 0.4 0.1 0.40-1.0 4.0-4.9 0.05-0.25 - -0.1 - 99
5754 Al Mg3 0.4 0.4 0.1 0.5 2.6-3.6 0.3 - 0.2 - 99
6061 Al Mg1SiCu 0.40-0.8 0.7 0.15-0.40 0.15 0.8-1.2 0.04-0.36 - 0.25 - 99
6063 Al Mg0.5Si 0.20-0.6 0.35 0.1 0.1 0.45-0.9 0.1 - 0.1 - 99
6082 Al Si1MgMn 0.7-1.3 0.5 0.1 0.40-1.0 0.6-1.2 0.25 - 0.2 - 99
7050 Al Zn6CuMgZr 0.12 0.15 2.0-2.6 0.1 1.9-2.6 0.04 - 5.7-6.7 0.06 99
7075 Al Zn5.5MgCu 0.4 0.5 1.2-2.0 0.3 2.1-2.0 0.18-0.28 - 5.1-6.1 0.2 99


Recommend Products

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 1

Application

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 2

Packing & Shipping

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 3
GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 4

Certificate

GB T 3190 Aluminium Pipe 6000 7000 Series Sample For Marine Applications 5

FAQ


How does your price quote ?
1 Lowest material cost in best quality
2 All the products are designed and product by ourselves to save product’s cost
3 Quote the price in hours with the best price to help the partner to open the market.



Do you support OEM or ODM?
Yes right ! we could accept client ‘s design and we produce according to client ‘s drawing and we provide free service of
installation face to face



What about the payment terms?
Our normal payment terms is 30% T/T as the prepayment and 70% balance need to be paid off before shipment, we also could accept L/C for good client who have been familiar with our factory for a few years
